Optical Resolution Chart
OpenCV calibtation target is a very popular test target with chessboard pattern 12*13 square grid array, the square sharp corner is high precision.OpenCV calibration software can easily obtain the calibration result data of the camera, Camera Calibration Using a Chessboard confirm the performance of the optical system, and determine the resolution of the camera lens.
Description
OpenCV calibration targets on Glass
OpenCV calibtation target is a very popular test target with chessboard pattern 12*13 square grid array, the square sharp corner is high precision.OpenCV calibration software can easily obtain the calibration result data of the camera, Camera Calibration Using a Chessboard confirm the performance of the optical system, and determine the resolution of the camera lens. The classical checkerboard calibration board is compatible with the calibration algorithm of most image processing algorithms.
Glass OpenCV calibration target is a quartz glass material calibratoin board,quartz glass is a valuable material, has high temperature resistance, very small coefficient of thermal expansion, good chemical thermal stability, and bubbles, stripes, homogeneity, and birefringence can be comparable to ordinary optical glass. Therefore, it is an essential optical material with high stability for optical systems working in various adverse situations.Since the glass is transparent and reflective,we recommend to use it with background light source.If you have the front light source,you can choose our glass test target which is covered with a aluminum layer to avoid the transparency and reflection.Please be mentioned that we can offer many kinds of calibration targets including standard and customized version.
OpenCV calibration target on glass part number:
Part Number | Outshell Size | Grid Array | Square Size | Pattern Size | Material |
VPO-030-2.0-G | 30*30mm | 12*13 | 2*2mm | 26*24mm | Quartz Glass |
VPO-045-3.0-G | 45*45mm | 12*13 | 3*3mm | 39*36mm | Quartz Glass |
VPO-060-4.0-G | 60*60mm | 12*13 | 4*4mm | 52*48mm | Quartz Glass |
VPO-76-5.0-G | 76*70mm | 12*13 | 5*5mm | 65*60mm | Quartz Glass |
VPO-88-6.0-G | 88*88mm | 12*13 | 6*6mm | 78*72mm | Quartz Glass |
VPO-111-8.0-G | 111*106mm | 12*13 | 8*8mm | 104*96 | Quartz Glass |
VPO-150-10.0-G | 150*140mm | 12*13 | 10*10mm | 130*120 | Quartz Glass |
VPO-220-15.0-G | 220*205mm | 12*13 | 15*15mm | 195*180 | Quartz Glass |
VPO-300-20.0-G | 300*280mm | 12*13 | 20*20mm | 260*240 | Quartz Glass |
WMO-360-25.0-? | 360*335mm | 12*13 | 25*25mm | 325*300 | Quartz Glass |
WMO-420-30.0-? | 420*390mm | 12*13 | 30*30mm | 390*360 | Quartz Glass |
We can also offer custom Planar Chessboard according to user’s computer vision requirements, please advise us your camera calibration requirements.
We offer drawing and sample for evaluation,hope our small MOQ and fast delivery service can save you time and money.
Glass OpenCV calibration target features:
Substrate: Quartz Glass (optcial glass for options)
Coating: Black coating / Chrome
Dimension: Standard and Custom
Tolerance: (μm)
Application:For Machine Vision Imaging Systems,Computer Vision, Robotic, 3D Reconstruction, Lab, Auto Pilot Vehicle Laboratory etc..
Factory Production Equipment :
Factory Quality Assurance and Quality Control :
We have full testing and 12 months guarantee.
Packing and shipment::
The packaging is careful, with soft fillers, multiple fall protection measures and fragile labels.
The weight is not heavy,so we always use express like UPS, Fedex, DHL,TNT or EMS.
